107 cm TimeCutter® ZS 4200S Zero Turn Riding Lawn Mower 74683
Product Information
- Model number: 74683
- Serial number: 412270000 - 417999999
- Product Type: Riding Products
Loading...
Assembly Drawings
Search for a part within assembly drawings:
-
Service Manual
-
Operator's Manual
-
Product Warranty
-
Setup Instructions
-
EU/UK Declaration of Conformity
Hourmeter Kit, 2011 and After Zero-Turn-Radius Riding Mower (Part number 116-5461)
SEAT COVER W/O ARM REST - TC 18IN (Part number 117-0096)
Jack Kit, Zero-Turn-Radius Side-Discharge or Rear-Discharge Riding Mow (Part number 127-6666)
Fuel Stabilizer .05 oz (Part number 130-2393)
4-CYCLE FUEL, SNOW AND LAWN, 32OZ CAN (Part number 131-3823)
Toro Premium Fuel Treatment (Part number 131-6572)
Replacement Blade Kit, TimeCutter Riding Mower with 42in Mower (Part number 137-1999-03P)
42in Recycler Kit, Riding Mower (Part number 137-7042)
Bagging Enhancement Kit, 42in Mowers for Zero-Turn-Radius Riding Mower (Part number 137-7048)
FRONT WEIGHT KIT (Part number 140-2050)
ASSIST BAR KIT (Part number 140-2052)
LED Light Kit (Part number 140-2056)
DELUXE SEAT KIT (Part number 140-2057)
ARMREST KIT (Part number 140-2058)
DECK FOOTLIFT ASSIST KIT (Part number 140-2059)
FLOORMAT KIT (Part number 140-2060)
JACK MOUNT KIT (Part number 140-2711)
Striping Kit, 42in and Riding Mowers (Part number 140-5198)
KIT-CASTER WHEEL (Part number 145-0475)
10W30 4-CYCLE ENGINE OIL 32 OZ BOTTLE (Part number 38280)
TORO 4-CYCLE SAE 30 OIL (32OZ BOTTLE) (Part number 38903)
COVER (Part number 490-7516)
Mower Deck Drive Belt, TimeCutter SS Riding Mower with 42-inch Mowing (Part number 79004)
TWIN BAGGER, TIMECUTTER 42IN STAMPED (Part number 79410)
ROPS KIT (Part number 79485)
SLOPE SENSOR KIT, TIMECUTTER (Part number 79486)
-
Model number
74683 -
Serial number
412270000 - 417999999 -
Product Name
107 cm TimeCutter® ZS 4200S Zero Turn Riding Lawn Mower 74683 -
Product Brand
Toro -
Product Type
Riding Products -
Product Series
Zero Radius Turn, Consumer -
Chassis Type
ZRT - Consumer -
Swath
107cm -
Discharge
Recycler & Side Discharge -
Engine/Motor Manufacturer
Briggs & Stratton -
Engine/Motor Size
500cc -
Engine/Motor Type
4 Cycle -
Engine Starter
Electric -
Transmission Type
Hydrostatic -
Traction Type
2wd
-
Engine: Spark Plug Gap
.030"/ .76mm -
Chassis: Tire Pressure
13 psi / 90 kPa -
Engine: Engine Oil Type
48 oz. (1.4 Liter) SAE 10w-30 /API SF or higher -
Chassis: Height of Cut Range
1.5-4.5"; 1/2" increments -
Engine: Engine Speed
2600±100 RPM -
Engine: Battery
12V 230CCA -
Drive System: Ground Speed
0-5 mph -
Engine: Ignition Coil Air Gap
0.011in (0.3mm) -
Drive System: Gearbox Lubricant
HYPR-OIL 500 / 20w-50 Synthetic Motor Oil -
Engine: Spark Plug
Champion XC92YC or Briggs & Stratton # 491055
