107 cm Cutting Width TimeCutter® ZS 4200T Riding Mower 74687

107 cm Cutting Width TimeCutter® ZS 4200T Riding Mower 74687

Product Information

  • Model number: 74687
  • Serial number: 400000000 - 406799999
  • Product Type: Riding Products

Hourmeter Kit, 2011 and After Zero-Turn-Radius Riding Mower (Part number 116-5461)
Jack Kit, Zero-Turn-Radius Side-Discharge or Rear-Discharge Riding Mow (Part number 127-6666)
Striping Kit, 42in and Riding Mowers (Part number 137-5030)
42in Recycler Kit, Riding Mower (Part number 137-7042)
Bagging Enhancement Kit, 42in Mowers for Zero-Turn-Radius Riding Mower (Part number 137-7048)
FRONT WEIGHT KIT (Part number 140-2050)
ASSIST BAR KIT (Part number 140-2052)
SUNSHADE KIT (Part number 140-2054)
LED Light Kit (Part number 140-2056)
DELUXE SEAT KIT (Part number 140-2057)
ARMREST KIT (Part number 140-2058)
DECK FOOTLIFT ASSIST KIT (Part number 140-2059)
FLOORMAT KIT (Part number 140-2060)
JACK MOUNT KIT (Part number 140-2711)
TWIN BAGGER, TIMECUTTER 42IN STAMPED (Part number 79410)
ROPS KIT (Part number 79485)
SLOPE SENSOR KIT, TIMECUTTER (Part number 79486)

  • Model number
    74687
  • Serial number
    400000000 - 406799999
  • Product Name
    107 cm Cutting Width TimeCutter® ZS 4200T Riding Mower 74687
  • Product Brand
    Toro
  • Product Type
    Riding Products
  • Product Series
    Zero Radius Turn, Consumer
  • Chassis Type
    ZRT - Consumer
  • Swath
    107cm
  • Discharge
    Recycler & Side Discharge
  • Engine/Motor Manufacturer
    Toro
  • Engine/Motor Size
    22.5 hp
  • Engine/Motor Type
    4 Cycle
  • Engine Starter
    Electric
  • Transmission Type
    Hydrostatic
  • Traction Type
    2wd

  • Engine: Spark Plug
    NGK BPR6ES
  • Engine: Spark Plug Gap
    .030"/ .76mm
  • Chassis: Tire Pressure
    13 psi / 90 kPa
  • Drive System: Ground Speed
    0-6 mph
  • Chassis: Height of Cut Range
    1.5-4.5"; 1/2" increments
  • Engine: Battery
    12V 230CCA
  • Engine: Engine Speed
    2850±100 RPM
  • Engine: Engine Oil Type
    77 oz. (2.3L) with filter change SAE 10w30/10w40
  • Engine: Ignition Coil Air Gap
    0.011in (0.3mm)
  • Drive System: Gearbox Lubricant
    20W50 Engine oil 54oz (1.687qt)
