30 in. (76.2 cm) Stand-On Aerator
Product Information
- Model #: 39521
- Serial #: 400000000 - 409760522
- Product Type: Aerators
Loading...
Assembly Drawings
Search for a part within assembly drawings:
-
Operator's Manual
-
Product Warranty
-
ACMA Declaration of Conformity
Spreader Attachment (Part # 33525)
The 24 in. or 30 in. stand-on aerator is compatible with the all-new spreader attachment. Now an operator can pull plugs and overseed with precision on a single machine.
-
Model #
39521 -
Serial #
400000000 - 409760522 -
Product Name
30 in. (76.2 cm) Stand-On Aerator -
Product Brand
Toro -
Product Type
Aerators -
Product Series
Turf Maintenance Equipment -
Chassis Type
Stand On -
Swath
30 inch -
Engine/Motor Manufacturer
Kawasaki -
Engine/Motor Size
603cc -
Engine/Motor Type
4 Cycle -
Engine Starter
Electric -
Transmission Type
Hydrostatic -
Traction Type
Rear WD
-
Engine: Battery
12V 300CCA -
Engine: Engine Speed
3600±100 RPM -
Engine: Spark Plug
NGK BPR4ES -
Engine: Spark Plug Gap
.030"/ .76mm -
Engine: Ignition Coil Air Gap
0.011in (0.3mm) -
Drive System: Ground Speed
Forward: 0-7 mph -
Chassis: Tire Pressure
12-14psi (83-97kPa) -
Drive System: Gearbox Lubricant
HYPR-OIL 500 -
Engine: Engine Oil Type
1.8 US QT (1.7L) w/ filter change; 1.6 US QT (1.5L) w/o filter; 10w-30 / 10w-40 oil API SF or higher
