4000 Series HDX Pro 52 in. (132 cm) 31 hp 999cc
Product Information
- Model #: 74010
- Serial #: 418000000 - 418028337
- Product Type: Riding Products
Loading...
Assembly Drawings
Search for a part within assembly drawings:
-
Operator's Manual
-
Product Warranty
-
Setup Instructions
HYPR-OIL 500 -QUART (Part # 114-4713)
HYPR-OIL 500-GALLON (Part # 114-4714)
HYPR-OIL 500-5 GALLON (Part # 114-4715)
SPARK ARRESTOR (Part # 117-3281)
Striper Kit (Part # 126-7882)
Jack Kit, Zero-Turn-Radius Side-Discharge or Rear-Discharge Riding Mow (Part # 127-6666)
TWEEL-TURF (Part # 139-3649)
RECYCLER KIT-G3/GRANDSTAND, 52 (Part # 139-6653)
BLADE-FLOW, HIGH (Part # 140-1242)
BLADE-18.00 MEDIUM FLOW (Part # 140-4856)
BLADE-18.00 LOW FLOW (Part # 140-4857)
BLADE-18.00 ATOMIC (Part # 140-4858)
BLADE-18.00 RECYCLER (Part # 140-4859)
6 PACK-BLADE, 18.00 HIGH FLOW (Part # 140-4882)
6 PACK-BLADE, 18.00 MED FLOW (Part # 140-4883)
6 PACK-BLADE, 18.00 LOW FLOW (Part # 140-4884)
6 PACK-BLADE, 18.00 ATOMIC (Part # 140-4885)
6 PACK-BLADE, 18.00 RECYCLER (Part # 140-4886)
BASE LIGHT KIT-4000 SERIES (Part # 144-0389)
TRIMMER MOUNT (Part # 144-2665)
KIT, JACK MOUNT (Part # 144-2676)
HARDTOP SUN CANOPY (Part # 144-3719)
52" CHUTE GATE KIT [4000] (Part # 144-6571)
HANDLE EXTENSION KIT (Part # 145-3615)
ASM-VOODOO TRAC 24X10.5-12 (Part # 147-5030)
BLADE-18.00 HIGH FLOW (Part # 147-6251)
6 PACK-BLADE, 18.00 HIGH FLOW (Part # 147-6255)
13X6.5N6 CASTER TWEEL ASM (Part # 147-6294)
Bucket Mount Kit, Z Master 2000 or 4000 Series Riding Mower (Part # 147-6345)
Universal Mount Kit, Z Master 2000 or 4000 Series Riding Mower (Part # 147-6346)
KIT-BAFFLE, TURBO FORCE (Part # 147-7361)
KIT-ELEC DECK LIFT (Part # 147-7867)
KIT-2IN RECIEVER HITCH (Part # 161-2810)
KIT-ACTUATOR REPLACEMENT,412200557 BE (Part # 161-3549)
KIT-ELEC DECK LIFT, SN 412200557 BELO (Part # 161-3550)
Fuel Pickup with Screen, Kit (Part # 161-6806)
BAGGER KIT, Z MASTER 2000 / 4000 (Part # 78439)
4000 Series E-Z Vac Blower & Drive Kit for 52" Deck (Part # 78465)
4000 Series E-Z Vac Blower & Drive Kit for 52" Deck - use with 4000 Series Twin Soft Bagger 48 - 60" Deck (#78463)
-
Model #
74010 -
Serial #
418000000 - 418028337 -
Product Name
4000 Series HDX Pro 52 in. (132 cm) 31 hp 999cc -
Product Brand
Toro -
Product Type
Riding Products -
Chassis Type
ZRT - LCE -
Swath
52 inch / 132 cm -
Discharge
Side Discharge -
Engine/Motor Manufacturer
Kawasaki -
Engine/Motor Size
31 hp -
Engine/Motor Type
4 Cycle -
Engine Starter
Electric -
Transmission Type
Hydrostatic -
Traction Type
Rear WD
