Z Master 4000

Product Information

  • Model #: 74057
  • Serial #: 416414584 - 417299999
  • Product Type: Riding Products
Anti-Scalp Kit, LH 400 and 500 Series w/TF Decks (Part # 108-4140)
HYPR-OIL 500 -QUART (Part # 114-4713)
HYPR-OIL 500-GALLON (Part # 114-4714)
HYPR-OIL 500-5 GALLON (Part # 114-4715)
SPARK ARRESTOR (Part # 117-3281)
Striper Kit (Part # 126-7882)
Jack Kit, Zero-Turn-Radius Side-Discharge or Rear-Discharge Riding Mow (Part # 127-6666)
SHOCK/SPRING ASM (Part # 136-8993)
RECYCLER KIT-G3/GRANDSTAND/GM 3300 60 (Part # 139-6655)
BLADE (Part # 140-1240)
BLADE-20.50 ATOMIC (Part # 140-1241)
BLADE-20.50 MEDIUM FLOW (Part # 140-4853)
BLADE-20.50, LOW FLOW (Part # 140-4854)
BLADE-20.50 RECYCLER (Part # 140-4855)
6 PACK-BLADE, 20.5 HIGH FLOW (Part # 140-4877)
6 PACK-BLADE, 20.5 MED FLOW (Part # 140-4878)
6 PACK-BLADE, 20.5 LOW FLOW (Part # 140-4879)
6 PACK-BLADE, 20.5 ATOMIC (Part # 140-4880)
6 PACK-BLADE, 20.5 RECYCLER (Part # 140-4881)
TRIMMER MOUNT (Part # 144-2665)
KIT, JACK MOUNT (Part # 144-2676)
HARDTOP SUN CANOPY (Part # 144-3719)
60" CHUTE GATE KIT (Part # 144-6572)
HANDLE EXTENSION KIT (Part # 145-3615)
TWEEL-TURF (Part # 147-4600)
BLADE-20.50 HIGH FLOW (Part # 147-6252)
6 PACK-BLADE, 20.50 HIGH FLOW (Part # 147-6256)
15INX6N6 CASTER TWEEL ASM (Part # 147-6337)
Bucket Mount Kit, Z Master 2000 or 4000 Series Riding Mower (Part # 147-6345)
Universal Mount Kit, Z Master 2000 or 4000 Series Riding Mower (Part # 147-6346)
KIT-BAFFLE, TURBO FORCE (Part # 147-7362)
KIT-ELEC DECK LIFT (Part # 147-7867)
KIT-2IN RECIEVER HITCH (Part # 161-2810)
BAGGER KIT, Z MASTER 2000 / 4000 (Part # 78439)
Empty Image Container
4000 Series E-Z Vac Blower & Drive Kit for 60" Deck (Part # 78466)
  • Model #
    74057
  • Serial #
    416414584 - 417299999
  • Product Name
    4000 Series MyRIDE® HDX 60" 35 hp 999cc
  • Product Brand
    Toro
  • Product Type
    Riding Products
  • Product Series
    Zero Radius Turn, Commercial 4000 Series
  • Chassis Type
    ZRT - LCE
  • Swath
    60 inch / 152 cm
  • Discharge
    Side Discharge
  • Engine/Motor Manufacturer
    Kawasaki
  • Engine/Motor Size
    35 hp
  • Engine/Motor Type
    4 Cycle
  • Engine Starter
    Electric
  • Transmission Type
    Hydrostatic
  • Traction Type
    Rear WD
  • Engine: Battery
    12V 300CCA
  • Engine: Spark Plug
    NGK BPR5ES
  • Engine: Spark Plug Gap
    .030"/ .76mm
  • Chassis: Tire Pressure
    13 psi / 90 kPa
  • Engine: Engine Oil Type
    filter chg 64 oz.(1.9 L); no filter chg 58 oz.(1.7 L); 10W-30 above -4F(-20C) or 5W-20 below 32F(0C)
  • Drive System: Ground Speed
    0-10 mph / 0-16kph
  • Engine: Engine Speed
    3750+50/-100 RPM
  • Chassis: Height of Cut Range
    1.5" - 5.5" (38-140mm)
  • Drive System: Gearbox Lubricant
    HYPR-OIL 500
