On Sale

GrandStand® 36 in. (91 cm) 15 hp 541cc

  • Model: 74534
  • UPC/EAN: 21038745343
See All Items in GrandStand® Gas Stand-On Mowers
Find a Dealer
  • Foldable operator platform instantly converts the machine to a walk-behind.
  • Exceptional visibility from the GrandStand protects the operator, the mower and the property. The operator is better able to steer clear of obstacles, and easily pass beneath branches.
  • With hefty cast iron spindles including maintenance free bearings plus only annual grease points, there will be less need for routine maintenance. That means less time spent off your mower and more time generating profits with it.
  • Conserves space to get more machines on your trailer, or allows for a smaller trailer and lighter load.
  • Horizon360® Business Management Software. Work More Efficiently. Run More Profitably.

Expert Setup & Delivery

Ground Shipping Only

Overview

Rough bumps and challenging terrain are all in a day’s work. Feeling them shouldn’t have to be. The Toro GrandStand combines the speed and comfort of a zero-turn rider with the on-and-off ease of a wide area walk-behind — creating a fast, maneuverable and more productive alternative. And now the GrandStand is even better with all-new next generation upgrades that add up to higher productivity, lower maintenance and easier service. This mower has a 15 hp (11kW) Kawasaki® FS541 engine with a 36 in. (91 cm) TURBO FORCE® deck.

Features

Fatigue-Reducing Suspension
Fatigue-Reducing Suspension
The revolutionary Flex-Ride operator platform suspension* keeps operators fresh, resulting in less fatigue and higher productivity throughout the day. Best of all, the suspension system is self-compensating for operators of different sizes.
2-in-1 Versatility
2-in-1 Versatility
Foldable operator platform instantly converts the machine to a walk-behind. It easily lowers back down when it’s time to ride, saving time and trailer space.
Stand-on Mower Productivity
Stand-on Mower Productivity
The ability to turn easily, get in and out of tight spaces, and quickly get on and off the mower to pick up debris or move obstacles all contribute to less time spent per property. The exceptional visibility of the GrandStand protects the operator, the mower and the property. The operator is better able to steer clear of obstacles, identify upcoming changes in terrain and easily pass beneath overhanging branches.
Exclusive TURBO FORCE Deck
Exclusive TURBO FORCE Deck
High-capacity TURBO FORCE decks deliver unsurpassed strength, a superior cut, and increased productivity in extreme mowing conditions. Equipped with a patented adjustable baffle, TURBO FORCE decks can be fine-tuned in order to conquer changing turf conditions.
Patented Adjustable Baffle
Patented Adjustable Baffle
Allows operator to achieve maximum cutting performance by fine-tuning deck to conquer changing conditions, unique job sites or different times of the season. In extreme conditions, the baffle can be opened in order to conserve power and achieve faster mowing speeds. In less demanding conditions, the baffle can be closed to yield micro-sized particles and maximize discharge velocity.
The Industry's Toughest Spindle Assembly
The Industry's Toughest Spindle Assembly
Toro's rugged spindle assemblies survive impacts that would destroy lesser spindles. The cast iron housing, with a massive 9-3/8" (23.8 cm) diameter base, absorbs impact loads and distributes them across a broader area of the robust deck shell.
Traction and Handling
Traction and Handling
The wide stance and optimal weight balance of the GrandStand enhance hillside stability and control. Because there are no restrictions to limit operator motion, operators can shift weight as needed to further enhance the performance of the machine.
Big on Features, Not Size
Big on Features, Not Size
The GrandStand conserves space to get more machines on your trailer or allows for a smaller trailer and a lighter load. And the unique, foldable operator platform makes the product even more compact for transport or storage. Some property owners have negative reactions to larger, heavier-looking mowers, and are concerned that their lawns may be damaged. With the sleeker Toro GrandStand, that problem is eliminated.
A Flat Crisp Cut with Precision Blades
A Flat Crisp Cut with Precision Blades
(.250) thick precision blades resist flexing to provide a flat, crisp cut. High-strength, heat-treated alloy steel survives impacts and provides resistance to the rapid wear commonly associated with abrasive conditions. Options include Recycler® and Atomic® mulching blades, medium sail Bahai blades, and low sail sand blades.
Smarter design in a bull-nose bumper.
Smarter design in a bull-nose bumper.
7-gauge bull-nose bumper not only protects against frontal impacts, but also contains an integral underskirt to minimize blowout of debris and dust. The bottom, leading edge of the deck is raised 1/4" (6 mm), allowing grass to stand more upright when entering the cutting chamber, ensuring a level cut. Leaf "plowing" during spring and fall clean-up also is significantly reduced.
Rubber Discharge Chute
Rubber Discharge Chute
High performance rubber discharge chute allows for close trimming without damaging chute or landscape structures. Patented design provides exceptional clipping dispersion.
Heavy-Duty Muffler Guard
Heavy-Duty Muffler Guard
Heavy-duty, 7-gauge muffler guard protects muffler against damage.
Flat-free, semi-pneumatic caster tires
Flat-free, semi-pneumatic caster tires
Flat-free, semi-pneumatic caster tires
Horizon360 system used by contractor
Horizon360® Business Management Software.
Managing and growing your business is hard work. Using a business management software system shouldn't make it harder. That is why we built Horizon360. If you can type and point/click a mouse, you have all the skills required.

For more information click here.

Specifications

Adjustable Discharge Baffle Standard
Blade Tip Speed 18,500 ft/min / 5,638 m/min
Blades 0.204 in. (0.5 cm) heat-treated steel
Box Dimensions 77.25 in. x 49 in. x 52 in. x 196.2 cm x 124.5 cm x 132.1 cm
CARB Compliant Not CARB Compliant
Carrier Frame 3 in. x 1.5 in. x 12 gauge (7.6 cm x 3.8 cm x 12 gauge)
Caster Tires 11 in. x 4 in. - 5 in. (28 cm x 10.2 cm - 12.7 cm) Flat-Free Semi-Pneumatic
Clutch Electromagnetic
Comfort Platform Foldable Operator Platform with Suspension
Controls Twin lever
Deck Design 7-gauge 36" (91 cm) TURBO FORCE® with bull-nose bumper
Deck Material 7 Gauge Steel
Deck Size 36 in / 91 cm
Discharge Chute Rubber
Drive System Pumps 10cc rev Wheel Motors 10 cir
Drive Tires 18 in. x 8.5 in. - 8 in. (46 cm x 22 cm - 20 cm)
Engine 15 hp* (11kW) Kawasaki® FS541V 603 cc
Engine Brand Kawasaki
Engine Displacement (cc) 603 cc
Engine Horsepower 15.0 hp
Forward Ground/Transport Speed Up to 8.0 mph / 12.8 kph
Front Bumper Reinforced Bull-Nose
Fuel Capacity 7.8 gal. / 29.5 L / 31.2 Qt.
Fuel Type Gasoline
Height of Cut 1.0 - 5.0 in. / 2.5 - 12.7 cm
Hour Meter Standard
Hydraulic Fluid Premium synthetic
Number of Blades 3
Product Type Stand-On Mowers
Product Use Commercial
Spindle Bearings Maintenance-free
Spindle Housing 9.375 in / 23.8 cm Diameter Cast Iron
Start Type Electric
Steering Controls Twin Lever
Weight 837 lbs / 379.7 kg

Disclaimer

*The gross horsepower of these engines was laboratory rated at 3600 rpm by the engine manufacturer in accordance with SAE J1940 or SAEJ2723. As configured to meet safety, emission and operating requirements, the actual engine horsepower on these mowers will be significantly lower.

Accessories

18 Inch High Flow Blade (6 Pack)
18 Inch High Flow Blade (6 Pack) (Part # 108-1117)
Atomic Blade Pack (6)
Atomic Blade Pack (6) (Part # 108-1118)
Low Flow 18 Inch Blade Pack (6)
Low Flow 18 Inch Blade Pack (6) (Part # 110-0406)
Recycler 18 Inch Blade Pack (6)
Recycler 18 Inch Blade Pack (6) (Part # 110-0408)
Mid Flow 18 Inch Blade Pack (6)
Mid Flow 18 Inch Blade Pack (6) (Part # 110-0409)
Genuine OEM Part 110-2080
36 Inch GrandStand Recycler Kit (Part # 110-2080)
Genuine OEM Part 114-3505
GrandStand Light Kit (Part # 114-3505)
Hypr-Oil™ 500 (quart)
Hypr-Oil™ 500 (quart) (Part # 114-4713)
Hypr-Oil™ 500 (gallon)
Hypr-Oil™ 500 (gallon) (Part # 114-4714)
Genuine OEM Part 114-4715
Hypr-Oil™ 500 Hydraulic Oil (5 gallon) (Part # 114-4715)
Genuine OEM Part 117-3620
GrandStand Weight Kit (Part # 117-3620)
Genuine OEM Part 117-8560
Stripping Kit (Part # 117-8560)
Empty Image Container
GrandStand Operator Chute Gate Kit (Part # 117-8565)
Oil Filter
Oil Filter (Part # 119-5852)
Genuine OEM Part 120-2235
Fuel Filter (Part # 120-2235)
Genuine OEM Part 120-7447
Air Filter Element - Primary (Part # 120-7447)
Genuine OEM Part 121-7515
Bagger Adapter Kit for 36in GrandStand Mower (Part # 121-7515)
Genuine OEM Part 121-7530
Trash Container Kit (Part # 121-7530)
Empty Image Container
36 inch Deck MVP Kit (GrandStand) (Part # 127-1646)
3 Bushell Soft Collection Bag for GrandStand Mowers
3 Bushell Soft Collection Bag for GrandStand Mowers (Part # 30104)
Genuine OEM Part 92-2153
Spark Plug (Part # 92-2153)
Toro Genuine Parts Logo
Spark Arrestor (Part # 98-9099)

Documents

Title Documents
GrandStand Mowers Sell Sheet PDF - Sellsheet-en-us



Warranty

4-Year / 750 Hours

**See dealer for Warranty details.
