On Sale

30 in TurfMaster® HDX

  • Model: 22225
  • UPC/EAN: 21038222257
See All Items in 30" TurfMaster® HDX
  • Made to Last - 13-gauge steel deck and heavy-duty components.
  • Toro Tough - Rubber tires with co-polymer wheels and ball bearings.
  • Reduced Refills - Less time refueling with the 1-gallon gas tank.
  • Horizon360® Business Management Software. Work More Efficiently. Run More Profitably.

Overview

We know that up time is everything when it comes to your business. Cut more grass in fewer passes than ever before with the TurfMaster's wide 30 in deck. You'll tackle hilly terrain and full bags of clippings with ease with a strong MV702 transmission. Every component from top to bottom is made for heavy use in rough conditions, from curbs and trailers to multiple operators. And you'll spend less time refueling with the large one-gallon gas tank. Not only is this mower built to last, it's also designed to give you the professional-quality cut your customers demand for even the most complex mowing jobs. And you can rest easy knowing that Toro stands behind its mowers with 1-year warranty. And as a Toro owner, you'll have access to nearly 3,000 servicing dealers across the U.S. and Canada ready to assist you. Count on it. Dimensions: 41 in x 32 in x 66 in (104.1 cm x 81.3 cm x 167.6 cm) (LxWxH)

Choose the right fuel for your mower. For best starting results use Non-ethanol fuel with an octane rating of 87 or higher. Use fresh fuel less than 30 days old, add fuel stabilizer to reduce starting problems. Do not mix oil with gas. For more information, view our Fuel Fact Tips.

Features

Impact Protection
Impact Protection
Steel bullnose front bumper, brush guard and engine guard protect components from damage.
Heavy-Duty Components
Heavy-Duty Components
Every component is designed for the jobs you need to perform, including the durable cast-aluminum frame, the heavy duty steel deck, and the bull-nose front bumper.
Commercial-Grade Wheels
Commercial-Grade Wheels
Rubber tires with co-polymer wheels feature precision ball bearings for long life with less downtime and lower replacement costs.
2-Point Height of Cut
2-Point Height of Cut
Heavy-duty 2-point height of cut (HOC) system makes it easy to adjust deck height. No need to walk around the mower to adjust four different levers.
Mulching System
Mulching System
Mulching system minces grass clippings for a "just bagged" appearance without the hassle of clipping collection and disposal.
Large 1-Gallon Gas Tank
Large 1-Gallon Gas Tank
A larger gas tank means longer mowing time between refueling.
Two-Bail Control System
Two-Bail Control System
Provides excellent speed control and is easy to operate.
Blade Brake Clutch (BBC)
Blade Brake Clutch (BBC)
Allows the operator to disengage the blades without shutting down the engine. Saves time restarting when you have to step away momentarily to move obstacles or empty the bag.
Highly Productive 30
Highly Productive 30" Deck
3-in-1 deck design provides mulching, bagging or side discharge and helps you finish the job faster.
1.1 Maximum Acres per Hour
1.1 Maximum Acres per Hour
Maximum acres per hour based on 90% efficiency (MPH x width of cut). Actual productivity dependent upon conditions.
Horizon360 system used by contractor
Horizon360® Business Management Software.
Managing and growing your business is hard work. Using a business management software system shouldn't make it harder. That is why we built Horizon360. If you can type and point/click a mouse, you have all the skills required.

For more information click here.

Specifications

Bagger Capacity 2.5 bushels
Blade Design 0.135 in. / 0.343 cm
Blade Engagement Blade Brake Clutch (BBC)
Blade Tip Speed 18,000 ft/min / 5,486 m/min
Box Dimensions 41.75 in x 33 in x 26 in / 106.0 cm x 83.8 cm x 66.0 cm
Deck Material 13 Gauge Steel
Deck Size 30 in / 76 cm
Drive System Variable Speed
Engine Kohler Command Pro 200 cc
Engine Brand Kohler
Engine Displacement (cc) 200 cc
Forward Mowing Speed Up to 4.0 mph / 6.4 kph
Fuel Capacity 1 gal. / 3.8 L / 4 Qt.
Fuel Type Gasoline
Height of Cut 1.5 - 5.0 in. / 3.8 - 12.7 cm
Mulch, Bag, Side Discharge Bag standard, Mulch standard, Side discharge standard
Number of Blades 2
Product Type Walk Behind Mowers
Product Use Commercial
Start Type Pull Cord
Tires Front: 9 in. x 2in. (22.8 cm x 5.0 cm) Rubber Tire w/Co-Polymer Wheels
Rear: 10.5 in. x 3 in. (26.6 cm x 7.6 cm) Rubber Tire w/Co-Polymer Wheels
Transmission Variable Speed Rear Wheel Drive
Weight 187 lbs / 84.2 kg

Disclaimer

*See retailer for warranty details.

Accessories

Empty Image Container
15.4 Inch Atomic Blade
15.4 Inch Atomic Blade (Part # 120-9500-03)
Empty Image Container
Walk Push Mower Mulching Kit (Part # 125-5064)

Documents

Title Documents
TurfMaster Brochure PDF - Sellsheet-en-us

Parts & Manuals

Select your model year from the options below to view parts & manuals.



Warranty

1-Year Limited Commercial Use, 2-Year Limited Commercial Use Engine

**See dealer for Warranty details.
