TimeCutter ZS 3200S Riding Mower
Product Information
- Model #: 74682
- Serial #: 400000000 - 999999999
- Product Type: Riding Products
Loading...
-
Operator's Manual
-
Product Warranty
-
EU Declaration of Conformity
-
Setup Instructions
18 inch Seat (Part # 119-8830)
Genuine OEM Part
Please contact your local dealer
All Season 4-Cycle Fuel for Lawn Mowers and Snow Blowers 32 oz. (Part # 131-3823)
4-cycle ethanol free fuel, engineered for maximum performance. Highly recommended for gas engines to maintain smooth performance. Advantages include cleaner fuel system, better fuel economy, longer shelf life and less wear and tear on internal engine parts. 92 plus octane for fast starts and optimal equipment performance.
Deluxe Seat Kit for TimeCutter Mowers (Part # 131-7699)
Genuine OEM Part
TimeCutter SS Foot Assist HOC System (Part # 79010)
The Toro Foot-Assist Height-of-Cut System allows operators to easily raise and lower the mower deck using their foot. This option is ideal for situations where the deck height or height-of-cut needs to be adjusted frequently. Specifically designed for Toro TimeCutter SS mowers, this product provides mechanical leverage to add convenience to your mower.
TimeCutter SS Sunshade (Part # 79011)
Keep cool and dry while you mow. The Toro TimeCutter sunshade increases operator comfort by shielding you from the elements. Assembles easily and offers a clean line of sight across your entire mowing area. Genuine Toro Parts and accessories are designed specifically for your machine and built to exacting standards with tight tolerances. Other parts simply don't stack up to the quality, performance, and value of Genuine Toro Parts.
dfdfdf (Part # 79414)
-
Model #
74682 -
Serial #
400000000 - 999999999 -
Product Name
TimeCutter ZS 3200S Riding Mower -
Product Brand
Toro -
Product Type
Riding Products -
Product Series
Zero Radius Turn, Consumer -
Chassis Type
ZRT - Consumer -
Swath
32 inch -
Discharge
Recycler & Side Discharge -
Engine/Motor Manufacturer
Toro -
Engine/Motor Size
452cc -
Engine/Motor Type
4 Cycle -
Engine Starter
Electric -
Transmission Type
Hydrostatic -
Traction Type
Rear WD
-
Engine: Ignition Coil Air Gap
.010" / .25mm -
Engine: Spark Plug
Champion RC12YC -
Engine: Spark Plug Gap
.030"/ .76mm -
Chassis: Tire Pressure
13 psi / 90 kPa -
Engine: Engine Oil Type
48 oz. (1.42 Liter) SAE 30 or 10W-30 or 10W-40 -
Chassis: Height of Cut Range
1.5-4.5"; 1/2" increments -
Engine: Engine Speed
2600±100 RPM -
Engine: Battery
12V 230CCA -
Drive System: Ground Speed
0-5 mph -
Drive System: Gearbox Lubricant
HYPR-OIL 500 / 20w-50 Synthetic Motor Oil
